Haisstronica Crimping Tool for Non-Insulated Open Barrel Terminals - Black body, blue/yellow handles, metallic jaws.
Precision-machined contact points ensure a tight, low-resistance mechanical and electrical bond for every crimp crimp
Versatile ratcheting crimp tool designed for various insulated terminals with quick-release trigger function ratcheting crimp tool
Industrial manual ratchet crimping tool with adjustable pressure settings for reliable electrical installation ratchet crimping tool
Rugged construction allows this heavy-duty electrical cable crimping tool to handle large gauge wires easily electrical cable crimping tool
Precision-engineered components ensure a tight, low-resistance bond with this portable electrical crimp tool electrical crimp tool
Heavy-duty jaws designed for diverse wire gauges demonstrate the quality of these essential crimping tools electrical crimping tools electrical
High-conductivity copper cable crimps featuring seamless barrels for maximum electrical performance cable crimps

Open Barrel Crimping Tool for Non-Insulated Terminals

$28.99 USD $30.99 USD
Save 6%

Shape the wings. Support the wire.

Open-barrel terminals need more than a flat squeeze.

• Open-barrel profiles — designed for supported 20–10 AWG terminal applications.
• Conductor and insulation support — match the appropriate wing position to each part.
• Adjustable operation — pressure adjustment and a release lever support controlled positioning.

Coupon strip showing 5 percent and 10 percent discounts by order value
Quantity:
Free Returns Within 30 Days
Free Shipping on All Orders
Warranty up to 24 Months
Visa Mastercard PayPalAmerican Express DiscoverDiners Club
Haisstronica crimper dies for AWG 10-14 wire terminals, designed for precision crimps in automotive/DIY projects.
Crimping Dies for Wire Terminals $13.99
Haisstronica model automatic cable stripper for precision tasks.
Self-Adjusting Wire Stripper AWG 24-10 $23.99

Open Barrel Crimping Tool for Non-Insulated Terminals helps prevent loose conductor connections when repairing compatible open-barrel terminals and automotive receptacles. The HX1219 supports the marked AWG 20-18, 18-14, and 12-10 positions; match both the wire gauge and terminal crimp profile before use.

Repairing ignition leads rather than general harness contacts? Use a dedicated spark plug wire crimping tool for compatible 8–8.5 mm ignition cable and matching spark plug terminals. An open-barrel harness die is not automatically compatible with an ignition-terminal profile.

Specifications

Terminal Type Supported AWG Die/Crimp Profile Ratchet/Adjustment Included Parts
Non-insulated open-barrel terminals and receptacles 20-18 Marked open-barrel crimp position Ratchet mechanism with release and pressure adjustment 1 crimping tool, SKU HX1219
Non-insulated open-barrel terminals and receptacles 18-14 Marked open-barrel crimp position Ratchet mechanism with release and pressure adjustment Tool only
Non-insulated open-barrel terminals and receptacles 12-10 Marked open-barrel crimp position Ratchet mechanism with release and pressure adjustment Tool only
Precision-machined contact points ensure a tight, low-resistance mechanical and electrical bond for every crimp crimp

❓Which terminal types are compatible?
Compatible non-insulated open-barrel terminals and receptacles within AWG 20-10.

❓What wire ranges are marked on the tool?
AWG 20-18, 18-14, and 12-10.

❓Can this replace an insulated-terminal crimper?
No. Open-barrel and insulated terminals require different crimp profiles.

❓How to Choose

Identify the terminal construction first. Match its conductor range and required crimp profile to the wire and the HX1219 jaw marked AWG 20-18, 18-14, or 12-10. Check conductor-wing and insulation-wing dimensions; an AWG match alone does not confirm fit. Follow the terminal manufacturer's crimp specification and use a dedicated tool if it is required. The listing includes one HX1219 crimping tool; select terminals separately.

❓How to Use

  1. Disconnect power and follow the equipment and terminal instructions.
  2. Strip the specified conductor-crimp length without cutting wire strands.
  3. Select the matching marked jaw and position the terminal wings in the specified orientation.
  4. Insert the conductor fully, keeping insulation out of the conductor-crimp area, and complete the ratchet cycle. Use the release mechanism if repositioning is needed.
  5. Inspect the conductor crimp and insulation support, then check retention as directed by the terminal instructions. Correct a loose or damaged crimp before restoring power.
  • Enjoy free shipping on all orders.
  • Delivery Time: 1-2 business days to The US and Canada. Delivery times may vary depending on your location and carrier conditions.
  • Details
  • Tracking: After your order is shipped, you will receive an email with a tracking number to monitor the delivery status.
  • Need Help? Contact our support team for assistance with shipping or your order.
  • 30-Day Returns
    You may request a return within 30 calendar days of delivery. Items must be unused, in their original condition, and include all original packaging and accessories.
  • Damaged, Defective, or Incorrect Items
    Contact us with your order number and photos. If the issue is due to our error, we will cover reasonable return shipping costs or provide an appropriate replacement.
  • Refunds
    Approved refunds are issued to your original payment method within 5 business days after inspection. Your bank may require additional processing time.
  • To start a return, email support@haisstronica.com with your order number and reason for return. Please obtain approval before sending anything back.
  • View Full Return & Refund Policy
  • 5 stars: 9 (90%)
  • 4 stars: 1 (10%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
R
Ronnie S.
Great crimper

Sturdy, delivered as expected

C
Champ131
Great buy

Yes worked perfectly o

P
Paul B.
Perfect

Perfect for Open barrel Terminals just what I was looking for.

N
Nartel Letran
Quality

Good product

M
Michael Erchul
Crimp tool

Im big on soldering all my connections and sometimes without a 3rd hand its hard to get everything perfect but I thought id give these a try. If you get the wires all little ed up and into this it will hold everything in place and then you crimp it down. Its supposed to give a perfect crimp every time but here in reality its more like a lot of the time. Not every crimp comes out perfect but a lot of them do. Then you can solder everything in place for a permanent fit. Its a solid tool and I'm Definitely not worried it will fall apart. I don't use it as much as some people might but I will get a lot of use out of it. It feels solid and doesn't wobble while crimping like some of the cheaper versions ive seen. It definitely earns a spot in the pouch!

t
tom quinlan
Great low price item

This is an excellent tool, works just as good as the name brand high dollar products

D
Diego Zapata
Muy Útil

Esta herramienta de prensado es de muy buena calidad muy útil a la hora de necesitar poner conectores a los cables

M
Michael V. Frazier
Good tool

It does what it is supposed to do vey nicely.

R
Robert Delgado
It does the job with perfection!!

This tool works fantastic and reasonably priced!!

K
Ken
Its a great purchase

Tool worked great for my truck light project. Would defiantly recommend doing a test crimp on a connector before doing the whole project.

Close-up of insulated wire connectors joining red, blue, and yellow wires

WELCOME TO THE HAISSTRONICA CLUB!

Subscribe for Extra 10% OFF Your First order

Learn More About Porduct

  • Crimper Tool:Work for non-Insulated Open Barrel Terminals Receptacles.The professional jaw can quickly and easily crimp wire terminals.The indentation will not damage the shell during the crimp. It firmly grasps the wires. Each crimper tool is marked with AWG22-20/20-18/18-14/12-10 for easy identification.
  • Precise Ratchet Structure:According to the pressure needed to crimp products of different sizes, the built-in thickened ratchet automatically adjusts to the appropriate position to ensure the safe completion of crimping with easy release of the handle.
  • Adjustable Crimp Force:The crimp height of the star wheel is adjustable to ensure the right amount of crimping force.
  • Ergonomic Design:The nylon, non-slip handle ensures comfortable and swift operation. There is a quick-release lever on the inside of the handle that opens the jaws.
  • Buyer Confidence:We stand behind the quality of our products. If for any reason you are not satisfied with your purchase,please contact us.We offer a 30-day money-back guarantee,and a 12-month replacement warranty giving customers a 100% Satisfaction Guarantee for risk-free purchases!

For vehicle restorers, technicians, and workshop users repairing compatible open-barrel terminals in automotive harnesses, appliances, and equipment. Browse open barrel connectors and confirm the terminal profile before choosing a tool. This is not an insulated-terminal, heat-shrink closed-barrel, ferrule, or large cable-lug crimper. A bare crimp is not waterproof; use the connection system specified for the working environment.

Haisstronica provides a complete ecosystem for high-quality wiring, ensuring every terminal crimp is precise and permanent. Our manual crimping tools are built as a dedicated solution for professional-grade terminations, turning every wire connector crimp into a rock-solid electrical path. Whether you are a technician or a weekend DIYer, this electrician crimping tool ensures that crimping connectors to your circuit is efficient, repeatable, and completely error-free.

The secret to a perfect finish lies in the built-in, thickened ratchet that automatically adjusts to the pressure needed for different terminal sizes. This electric crimp tool mechanism guarantees the safe completion of every connector crimp, while the adjustable star wheel allows you to fine-tune the crimping force for varying wire gauges. Unlike standard manual crimping tools, this system ensures that your crimps electrical joints are uniform, providing consistent mechanical tension without the risk of over-crimping or loose wires.

Comfort and control are vital for complex projects, which is why our electric crimper features a nylon, non-slip handle for swift operation. These terminal crimpers tools include an integrated quick-release lever inside the handle, allowing you to open the jaws instantly to reposition a terminal if needed. This ergonomic design reduces hand fatigue and ensures that every wire crimp connector is seated perfectly before the final squeeze, making it an essential electric wire crimper for marine, automotive, and home wiring harnesses.

For the ultimate result, we recommend the "Perfect Combination" of using Haisstronica electric crimpers with our high-purity wire crimping terminals. This matched crimping tool electrical set is optimized to handle a wide range of wire crimp terminal types, including rings, spades, and butt splices. By pairing the right tool with our specialized connectors, you ensure that every wire connector crimp is vibration-resistant and corrosion-proof, delivering a level of reliability that generic electrician crimping tool sets simply cannot match.

Because real reliability is about more than just a tool, Haisstronica stands behind every crimp terminals tools set with a 100% satisfaction guarantee. We offer a 30-day money-back guarantee and a 12-month replacement warranty on all our electric crimpers, ensuring a risk-free purchase for every project. If your electrical crimps ever fall short of expectations, our support team is ready to help with troubleshooting or sizing advice—keeping your connections powered, sealed, and confident for the long term.
